codi::AggregatedActiveType< T_Real, T_InnerActiveType, T_Impl > Struct Template Reference

Represents a concrete aggregated lvalue int the CoDiPack expression tree. More...

#include <aggregatedActiveType.hpp>

Inheritance diagram for codi::AggregatedActiveType< T_Real, T_InnerActiveType, T_Impl >:

Public Types
using	Base
	Abbreviation for base class.
using	Impl = T_Impl
	See AggregatedActiveType.
using	InnerActiveType = T_InnerActiveType
	See AggregatedActiveType.
using	PassiveReal = RealTraits::PassiveReal<Real>
	Passive value type of the real.
using	Real = T_Real
	See AggregatedActiveType.
using	Traits = RealTraits::AggregatedTypeTraits<Real>
	The traits for the aggregated type.
Public Types inherited from codi::AggregatedActiveTypeBase< T_Real, T_InnerActiveType, T_Impl, false >
using	ADLogic
	AD logic that governs the expression. Needs to be the same for all inputs of the expression.
using	Impl
	See AggregatedActiveTypeBase.
using	InnerActiveType
	See AggregatedActiveTypeBase.
using	InnerIdentifier
	Identifier of the underlying tape.
using	InnerReal
	Inner real type of the active type.
using	Real
	See AggregatedActiveTypeBase.
using	StoreAs
	Implementation of ExpressionInterface.
using	Tape
	The tape of the inner active type.
using	Traits
	The traits for the aggregated type.
Public Types inherited from codi::ExpressionInterface< T_Real, T_Impl >
using	ADLogic = char
	AD logic that governs the expression. Needs to be the same for all inputs of the expression.
using	Impl = T_Impl
	See ExpressionInterface.
using	Real = T_Real
	See ExpressionInterface.
using	StoreAs = ExpressionInterface
	Defines how this expression is stored in an expression tree.
Public Types inherited from codi::NodeInterface< T_Impl >
using	Impl = T_Impl
	See NodeInterface.
Public Types inherited from codi::ExpressionMemberOperations< T_Real, T_Impl, typename >
using	Impl = T_Impl
	See ExpressionMemberOperations.
using	Real = T_Real
	See ExpressionMemberOperations.

Public Member Functions
	inlineAggregatedActiveType (AggregatedActiveType const &expr)
	Constructor.
template<typename Expr>
	inlineAggregatedActiveType (ExpressionInterface< Real, Expr > const &expr)
	Constructor.
	inlineAggregatedActiveType (PassiveReal const &expr)
	Constructor.
inlineImpl &	operator= (AggregatedActiveType const &expr)
	Assign operation.
template<typename Expr>
inlineImpl &	operator= (ExpressionInterface< Real, Expr > const &expr)
	Assign operation.
inlineImpl &	operator= (PassiveReal const &expr)
	Assign operation.
inline	~AggregatedActiveType ()=default
	< Use base constructors.
Public Member Functions inherited from codi::AggregatedActiveTypeBase< T_Real, T_InnerActiveType, T_Impl, false >
inlineInnerReal	applyAdjoint (Real const &adjoint) const
inlineInnerReal	applyAdjoint (Real const &adjoint) const
inlineReal	applyTangent (InnerReal const &tangent) const
inlineReal	applyTangent (InnerReal const &tangent) const
inlineInnerActiveType const &	getLink () const
	an expression.
inlineInnerActiveType const &	getLink () const
	an expression.
inlineReal const	getValue () const
	Compute the primal value that is usually evaluated by the statement/expression.
inlineReal const	getValue () const
	Compute the primal value that is usually evaluated by the statement/expression.
	inlineAggregatedActiveTypeBase ()=default
	Constructor.
	inlineAggregatedActiveTypeBase ()=default
	Constructor.
	inlineAggregatedActiveTypeBase (AggregatedActiveTypeBase const &)=default
	Constructor.
	inlineAggregatedActiveTypeBase (AggregatedActiveTypeBase const &)=default
	Constructor.
inline	~AggregatedActiveTypeBase ()=default
	Destructor.
inline	~AggregatedActiveTypeBase ()=default
	Destructor.
Public Member Functions inherited from codi::ExpressionInterface< T_Real, T_Impl >
inlineImpl const &	cast () const
	Cast to the implementation.
	ExpressionInterface ()=default
	Constructor.
	ExpressionInterface (ExpressionInterface const &)=default
	Constructor.
inlineReal const	getValue () const
	Compute the primal value that is usually evaluated by the statement/expression.
template<size_t argNumber, typename Tangent>
inlineauto	applyTangent (Tangent const &tangent) const
template<size_t argNumber, typename Adjoint>
inlineauto	applyAdjoint (Adjoint const &adjoint) const
Public Member Functions inherited from codi::NodeInterface< T_Impl >
inlineImpl const &	cast () const
	Cast to the implementation.
template<size_t argNumber>
char const &	getLink () const
	an expression.

Protected Member Functions
template<typename Rhs>
inlinevoid	store (ExpressionInterface< Real, Rhs > const &rhs, EventHints::Statement const &eventType)
	Has to be called by an AD variable every time it is assigned.
Protected Member Functions inherited from codi::AggregatedActiveTypeBase< T_Real, T_InnerActiveType, T_Impl, false >
inlineImpl &	cast ()
	Cast to implementation.
inlineImpl &	cast ()
	Cast to implementation.
inlineImpl const &	cast () const
	Cast to implementation.
inlineImpl const &	cast () const
	Cast to implementation.
Protected Member Functions inherited from codi::ExpressionMemberOperations< T_Real, T_Impl, typename >
inlineImpl const &	cast () const
	Cast to implementation.

Additional Inherited Members
Static Public Member Functions inherited from codi::AggregatedActiveTypeBase< T_Real, T_InnerActiveType, T_Impl, false >
static inlinestd::string	getMathRep ()
	Get the math symbol of the operation. E.g. + for operators and pow() for functions.
static inlinestd::string	getMathRep ()
	Get the math symbol of the operation. E.g. + for operators and pow() for functions.
Public Attributes inherited from codi::AggregatedActiveTypeBase< T_Real, T_InnerActiveType, T_Impl, false >
InnerActiveType	values [Elements]
	Array representation.
InnerActiveType	values [Elements]
	Array representation.
Static Public Attributes inherited from codi::AggregatedActiveTypeBase< T_Real, T_InnerActiveType, T_Impl, false >
static int constexpr	Elements
	The number of elements in the aggregated type.
static int constexpr	Elements
	The number of elements in the aggregated type.
static bool constexpr	isStatic
	See AggregatedActiveTypeBase.
static bool constexpr	isStatic
	See AggregatedActiveTypeBase.
static size_t constexpr	LinkCount
	Implementation of NodeInterface.
static size_t constexpr	LinkCount
	Implementation of NodeInterface.
static size_t constexpr	LinkCount = false
	handle the expression as a leaf node.

Detailed Description

template<typename T_Real, typename T_InnerActiveType, typename T_Impl>
struct codi::AggregatedActiveType< T_Real, T_InnerActiveType, T_Impl >

Represents a concrete aggregated lvalue int the CoDiPack expression tree.

An aggregated type, in the sense of CoDiPack, is a structure that can be expressed by a set of double values. E.g. std::complex<double> can be represented by two double values. The use case of this class is to be able to add such types to the CoDiPack expression tree. If you use std::complex<codi::RealReverse>, then the expression tree for operations on the complex number is usually quite short. When a and b are complex numbers with a CoDiPack type, then c = sin(a) + cos(b) would record at least 6 statements. If complex numbers are integrated into the expression tree, then only one or two statements are recorded.

In order to add an aggregated type to the CoDiPack expression tree, the traits codi::RealTraits::AggregatedTypeTraits need to be specialized for the aggregated type. The helper codi::RealTraits::ArrayAggregatedTypeTraitsBase can be used if the aggregated type can be interpreted as an array of values. In addition this class needs to be extended and special constructors and assignment operators need to be implemented.

An example is described in Tutorial 7 - Aggregated type implementation.

Template Parameters

T_Real	Real value of the aggregated type. (E.g. std::complex<double>)
T_InnerActiveType	CoDiPack type that composes the aggregated type. (E.g. codi::RealReverse)
T_Impl	The final implementation of the aggregated type.

Member Typedef Documentation

Base

template<typename T_Real, typename T_InnerActiveType, typename T_Impl>

using codi::AggregatedActiveType< T_Real, T_InnerActiveType, T_Impl >::Base

Initial value:


          AggregatedActiveTypeBase<T_Real, T_InnerActiveType, T_Impl, false>

Abbreviation for base class.

Constructor & Destructor Documentation

~AggregatedActiveType()

template<typename T_Real, typename T_InnerActiveType, typename T_Impl>

inline codi::AggregatedActiveType< T_Real, T_InnerActiveType, T_Impl >::~AggregatedActiveType ( )

default

< Use base constructors.

Destructor.

Member Function Documentation

store()

template<typename T_Real, typename T_InnerActiveType, typename T_Impl>

template<typename Rhs>

inlinevoid codi::AggregatedActiveType< T_Real, T_InnerActiveType, T_Impl >::store ( ExpressionInterface< Real, Rhs > const & rhs, EventHints::Statement const & eventType )

inlineprotected

Has to be called by an AD variable every time it is assigned.

Update of the value is performed by the tape. The tape will additionally store information, e.g., for the reversal of the statement.

Template Parameters

Lhs	Has to implement LhsExpressionInterface.
Rhs	Has to implement ExpressionInterface.

---

The documentation for this struct was generated from the following file:

• include/codi/expressions/aggregate/aggregatedActiveType.hpp
